28
Mount the sonar: slide the unit onto the bracket from above.
Adjust viewing angle: use one hand to press and release the spring-
loaded ratchets while you move the unit with the other hand.
Portable Sonar Installation
Like many Eagle products, the Cuda 242 sonar is capable of portable
operation. It uses the optional PPP-12 portable power pack.
Bracket front
Depress
ratchets to
release
