33
CAUTION:
Failure to use the enclosed 3-amp fuse will void your warranty! For
a replacement, use a type 3AG 3-amp fuse.
This unit has reverse polarity protection. No damage will occur if the
power wires are reversed. However, the unit will not work until the
wires are attached correctly.
Mounting the Sonar Unit: In-Dash or Bracket
You can install the sonar unit on the top of a dash with the supplied
bracket. It can also be installed in the dash with an optional FM-6
dash-mounting kit.
In-dash mounting template for Cuda 250.
NOTE: This figure is not printed to scale.
Top
ALWAYS VERIFY DIMENSIONS.
Cut along this line
www.Busse-Yachtshop.de email: info@busse-yachtshop.de
