Eagle Optima - Speed;Temperature Sensors

3
RED
WIRE
3 amp
FUSE
BLACK
WIRE
12 VOLT
BATTERY
TO SPEED/TEMP
OR TEMP SENSORS
(Not included)
POWER CONNECTIONS
To
Optima
SPEED/TEMPERATURE SENSORS
The Optima accepts up to three temperature sensors which can monitor
surface water, live well, air, and virtually any other temperature. You do
need to be careful when purchasing the temperature sensors, however.
Each temperature sensor has its own "address". The sensors are labeled
"Water", "T-2" (or Temp-2), and "T-3" (or Temp-3). If you want two (or
more) temperature readings, you'll need to use the proper sensors. For
example, you can't use two T-3 sensors. The sensors that will fit the Optima
are:
TS-1BK One sensor for "Water" temperature display.
TS-2BK One sensor for "T-2" temperature display.
TS-3BK One sensor for "T-3" temperature display.
TS-12BK Two sensors for "Water" and "T-2" temperature displays.
ST-TBKOne speed sensor and one temperature sensor for
"Speed" and "Water" displays.
You can combine these sensors in many combinations. See the list on the
following page for temperature and speed sensor combinations.
