Eagle T100 - One-Way Knurled Roller Assembly; Guide Pulley Assembly

- 22 -
Description Part Number Qty
1 Locknut M8LN 1
2 Nut M8LN 1
3 Washer FJ-02-03 1
4 Bearing HF-1216 1
5 One Way Roller
FJ-E-34-01
1
6 Shaft
FJ-00-04
1
7 Axle Sleeve FJ-02-01 1
6.10 Guide Pulley Assembly - FG-GUIDEPA (can be order as set)
Description Part Number Qty
1 Shaft
FJ-00-03
1
2 Axle Sleeve
FJ-02-07
1
3 Bearing Bushing
FJ-02-08
1
4 M5 Lock Washer
M5LOCKWASHER
1
5 Socket Head Cap Screw M5X12SHCS 1
6. Illustrations & Parts List
If you have a stainless steel model, please add -SS to any metal part when ordering.
6.9 One Way Knurled Roller Assembly - FJ-E-34A (can be order as set)
