27
TRANSMISSION
TRANSAXLECASEEXTENSION&RETAINER—ALLWHEELDRIVE‐DETAIL
Item Part Number Qty Description
1 6501474 10 SCREW-HEX CAP-W/ WASHER M8-1.25 X 16
2 4471573 1 PAN
3 82180 1 GASKET (USE SILICONE ADHESIVE)
4 NPN 1 CUP(NOT SOLD SEPARATELY)
5 4504568 1 SPACER KIT
6 4269787 1 RETAINER, OIL
7 4567493 1 RETAINER, BEARING
6500368 6 SCREW-HEX CAP-M8 X 1.25 X 23
8 4412522 1 SEAL, DIFFERENTIAL BRG.RET
9 4659342 1 COVER, TRANS. END
82180 1 GASKET (USE SILICONE ADHESIVE)
6501474 10 SCREW-HEX CAP W/WASHER M8-1.25 X 16
10 3878447 1 SEAL, MANUAL VALVE SHAFT
11 4471573 1 PAN, TRANSAXLE OIL
12 6101285 1 SCREW-HEX CAP-W/ WASHER M6-1 X 16
13 4567022 1 CUP
14 4567494 1 RETAINER
15 6500111 1 O-RING
16 4549219 1 OUT PUT HOUSING
6500511 4 SCREW-HEX CAP-W/ WASHER M8-1.25 X 33
17 NPN 1 BUSHING (SERVICED IN EXT.)
18 4412522 1 SEAL
19 6501474 10 SCREW-HEX CAP M8-1.25 X 15
20 NPN 1 SCREW-HEX CAP-WASHER HEAD M6-1.0 X
21 5212151 1 O-RING
22 4295857 1 SPEEDOMETER CABLE ADAPTOR
23 NPN 1 SCREW-FLAT HEAD HEX SOCKET M8-1.25 X
24 NPN 6 SCREW-HEX CAP-WASHER HEAD M8-1.25 X
26 A-TT5D-00021 1 DIFFERENTIAL-WELDED SPIDER GEAR
27 NPN 4 SCREW-HEX CAP WASHER HEAD M8-1.25 X
