Eagle TT-10 - Steering System Breakdown (for Serial Numbers Starting before 12136 & Below); Steering System Breakdown-Detail


51
STEERINGSYSTEM
STEERINGSYSTEMBREAKDOWN—DETAIL
Item PartNumber
Q
t
y
Descri
p
tion
1A‐TT10‐00809 1 STEERINGWHEEL
2A‐TT10‐00807‐11STEERINGCOLUMN
3A‐TT10‐00811 1 HORNBUTTON
4A‐TT10‐00801 1 CHARLYNNCONTROLPUMP
5A‐TT10‐00831 8 FITTING‐ADAPTOR
6A‐TT10‐0001 1 FITTING90DEGREE
7A‐TT10‐00821 1 HYDRAULICSTEERINGLINE22ʺ
8A‐TT10‐00822 1 HYDRAULICSTEERINGLINE43ʺ
9 NPN 2 HYDRAULICCYLINDE RPIVOTPIN
10 A‐TT10‐00823 1 HYDRAULICSTEERINGLINE32ʺ
11 A‐TT10‐00826 2 BEARING
(
AFTER7/99
)
12 NPN 7 HOSECLAMP
13 A‐TT10‐00819 2 STEERINGMOUNTINGBLOC
K
14 A‐TT10‐00817 2 DRAGLIN
K
15 A‐TT10‐00824 1 HYDRAULICSTEERINGLINE22.5 ʺ
16 A‐TT10‐00825 1 HYDRAULICSTEERINGLINE32ʹ
17 A‐TT10‐00406 2
J
AMNUT
18 A‐TT10‐00407 2 TIERODEND
19 NPN 1 HIGHPRESSUREHOSE
20 NPN 8 SCREWHEXCAP1/2‐20X21/4
21 NPN 8 WASHERFLAT1/2
22 A‐TT10‐00820 2 STEERINGARM
(
MACH INE D
)
23 NPN 2 NUTHEXSLOTTED
24 C‐5707X6 2 FITTING‐TEE
25 A‐TT10‐00803 2 HYDRAULICCYLINDE R
26 NPN 2 SETSCREW5/1 618X3/8
27 NPN 4 CLIP
28 A‐TT10‐00813 1 W HEELNUT13/16‐20
*Steeringcylindermustbeadjustedsowheninfullturntotherightandthemfullturntotheleftthecylinderdoesnot
pullsteeringarmmorethan3/16ofaninch.IfyouhaveanyquestionspleasecallEagleTugstechnicaldepartment.

