Eagle TT-10 - Parking Brake Actuator Assembly-Detail


47
BRAKES
PARKINGBRAKEACTUATORASSEMBLY—DETAIL
Item PartNumbe r
Q
t
y
Descri
p
tion
1A‐TT4 ‐00141 1 HANDBRAKE
2NPN4SCREW‐HEXCAP‐5/16‐18X1
3NPN4WASHER‐FLAT‐5/16
4NPN4NUT‐LOCK‐5/1 6‐18
5B‐TT4 ‐00145 1 CABLEPRIMARY
6A‐TT4 ‐00146 1 BAREQUALIZER
7NPN3CLEVISPIN
8 NPN 3 COTTER PIN
9A‐TT4 ‐00150 1 PARKINGBRAKECABLELEFTREAR
10 A‐TT4‐00150 1 PARKINGBRAKECABLERIGHTREAR
11 NPN 1 SCREW ‐HEXCAP‐14 ‐20X1
12 NPN 1 W ASHER‐FLAT‐1/4
13 NPN 1 NUT‐LOCK‐1/4‐20
14
NPN 1 SCREW‐HEXCAP‐1/4‐28X1
15 NPN 1 CABLECLAMPPLATE
16 NPN 1 CABLECLAMPHANDLE
17 NPN 2 NUT‐LOCK‐1/4‐28
18 NPN 2
CABLECLAMP
THEFOLLOWINGITEMSARENOTSHOWN
19 AE-OPT-0069 HAND BRAKE "ON" WARNING (OPTION)
20
AE-OPT-0069 SHUTDOWN HAND BRAKE "ON" SHUTDOWN (OPTION)
21
275.12 BUZZ LITE FOR PARKING BRAKE
22
81008429 CONTACT PIN
23 82050000 PROXIMITY SENSOR
24
82066700 MOUNTING SCREW
25
332-209-150 RELAY
26
A-TT4-00250 NEUTRAL SAFETY SWITCH
