Eagle TT-10 - Steering System Breakdown-Detail


49
STEERINGSYSTEM
STEERINGSYSTEMBREAKDOWN—DETAIL
Item PartNumber
Q
t
y
Descri
p
tion
1A‐TT10‐00809 1 STEERINGWHEEL
2A‐TT10‐00807‐11STEERINGCOLUMN
3A‐TT10‐00811 1 HORNBUTTON
4A‐TU‐00801 1 CHARLYNNCONTROLPUMP
5A‐TT10‐00831 8 FITTING‐ADAPTOR
6A‐TT10‐00 01 1 FITTING90DEGRE
E
7A‐TT10‐00821 1 HYDRAULICSTEERINGLINE22ʺ
9 NPN 1 H YDRAULICCYLIND E RPIVOTPIN
11 A‐TT10‐00826 1 BEARING
(
AFTE R7/99
)
12 NPN 7 HOSECLAMP
14 A‐TT10‐00817 1 DRAGLIN
K
15 A‐TT10‐00829 1 HYDRAULICSTEERINGLINE46ʺ
16 A‐TT10‐00822 1 HYDRAULICSTEERINGLINE43ʺ
17 A‐TT10‐00406 1
J
AMNUT
18 A‐TT10‐00407 1 TIERODEND
19 NPN 1 HIGHPRESSUREHOS
E
23 NPN 1 NUTHEXSLOTTE
D
25 A‐TT10‐00803‐1 1 *HYDRAULICSTEERINGCYLINDE R
27 NPN 2 CLIP
28 A‐TT10‐00813 1 W HEELNUT13/16‐20
29 AE‐OPT‐0160
(
OPTION
)
1STEERINGCOLUMNTURNSIGNALSWITC
H
30 AE‐OPT‐0160‐A
(
OPTION
)
112VFLASH ERTURNSIGNAL
*Steeringcylindermustbeadjustedsowheninfullturntotherightandthemfullturntotheleftthecylinderdoesnot
pullsteeringarmmorethan3/16ofaninch.IfyouhaveanyquestionspleasecallEagleTugstechnicaldepartment.

