OPERATORCOMPARTMENT
TRANSMISSIONCONTROL
Item PartNumber
Q
t
y
De scri
p
tion
1A‐TT4‐0 0245 1 TRANSMISSIONSHIFTCONTROL
2A‐TT4‐0 0246 1 TRANSMISSIONSHIFTCABLE
3A‐TT4‐0 0248 1 TRANSMISSIONCABLEBRACKETASSEMBLY
4A‐TT4‐0 0247 1 U‐BOLTKIT
5A‐TT4‐0 0249 1 BALL
J
OINTKIT
6A‐TT4‐0 0419 1 TRANSMISSIONLEVER
7 3020 08 1 INDICATORSTRIPREPAIRKIT
8 3023 48 1 HANDLEREPAIRKIT
TRANSMISSIONCONTROL—DETAIL
