Eagle TT-10 - Front End Alignment Procedure


83
FRONTENDALIGNMENTPROCEDURE
+1/16TOEOUT
FRONTTIRES
Findcenterlineoftirefrontandback
Checkwithtapemeasuretoseedifference
Thefrontshouldbe1/16inchmorethattherear
1/16inchtoeout,iflessorgreaterloosenthetwoboltsonthetierodclamp
Turnclampinorouttoachievedesiredsetting—1/16intoeou
t
Retightentwoboltsonthetierodclamp
TIERODCLAMP&BOLT
