33
Item PartNumbe r
Q
t
y
Descri
p
tion
1A‐TT1 0‐00371 1 COMPLETEAXLEASSEMBLY
2 706999‐14X 1 GEAR&PINIONASSEMBLY
3*SEEKIT 1 SLINGER‐PINIONOILINNER
4 706060X KIT INNERPINIONBEARING
5*SEEKIT KIT SH IM‐PINIONAD
J
USTING
6*SEEKI T 1 BAFFLE ‐PINIONOIL
7*SEEKIT KIT SHIM‐PINIONBEARINGAD
J
USTING
8 706045X KIT OUTERPINIONBEARING
9*SEEKIT 1 SLINGER‐PINIONOILOUTER
10 35725 1 SEAL‐OIL
11 345731X 1 ENDYOKEASSY
12 30275 1 W ASHER‐PINIONNUT
13 30271 1 NUT‐PINION
15 73591X 1 COVER‐CARRIER
16 82180 1 RTVSEALANT
16A 39697 1 GASKET
17 36472 1 PLUG‐PIPESQDRIV
E
18 34822 10 SCREW ‐FLANGE H
D
19 NOTSOLDSEPERATELY 2 CAPDIFFERE NTIALBEARING
20 500400‐20 2 1/2‐13X2.25GRD8HEXBOLT
21 706047X KIT DIFFERENTIALBEAR ING
22 *SEEKIT KIT D IFFERE NTIALSHIM
23 *SEEKIT 1 CASE‐DIFFERE NTIALASSY
24 30266 10 SCREW‐HEX
25 *SEEKIT 2 PINION‐DIFFERENTIAL
26 *SEEKIT 2 GE AR‐DIFFERENTIALKIT
27 *SEEKIT 2 TH RUSTWASHERDIFFERENTIALPINION
28 *SEEKIT 2 TH RUSTWASHERDIFFERENTIALGEAR
29 *SEEKIT 1 SH AFT‐DIFFERE NTIAL
30 500598‐22 1 PIN‐ROLL
31 16979 1 VENTPLUG
32 37275 2 SEAL&GUIDE‐SHAFT
33 SEEKIT706395‐X2 SEAL‐KINGPI
N
34 SEEKIT706395‐X2 RETAINER
35 SEEKIT706395‐X2BEARINGKINGPIN
36 41777 1 OILSEAL
37 044TR115‐24X 2 TIERODASSY
38 31026‐32BOLTSTOP
39 05QE 2
J
AMNUT
40 620180 2 RETAINER‐COMPRESSIONSPRING
41 37300 2 COMPRESSIONSPRING
42 500357‐13 8 LOCKWASHER
43 500412‐12 8 BOLT‐KINGPINBEARINGCAP
44 500175‐12FITTING‐LUBRICATION
45 37299 2 KINGPINCAP
46 37307 2 GASKET‐KINGPINCAP
47 41886 2 BUSHING‐KINGPIN
48 37302 2 KINGPIN
49 73948‐X 1 (3)RIGH THANDSTEERINGKNUCKLE
AXLES
AXLEASSEMBLYBREAKDOWN—FRONTDRIVE(ALLWHEELDRIVE)
