9
● Thoroughly clean all of these parts. Lightly oil the
p
iston and slide it in and out of the cylinder to
d
istribute the oil over the mating parts, reassemble
all of the components to their original
p
ositions (see page 8).
Please be aware that certain parts of this Paint Sprayer will wear, requiring replacement and that these
parts are not covered by guarantee. These parts include the Valve Assembly (3a), Nozzle (1 & 2),
Piston and Spring (3b & 3c). The wear on these parts depends on the abrasiveness of the paints being
sprayed. You would normally expect to replace an atomiser valve after spraying between 25-45 litres
of materials.
A worn valve will cause a poor spray pattern and will require replacing. Replacement valves are
available from the Earlex Service Department (see page 11 for contact details).
You will need to check the spray nozzles, Piston and Spring from time to time to check for wear.
Replace if necessary.
NEVER DISPOSE OF PAINTS OR SOLVENTS INTO DRAINS. CONTACT YOUR LOCAL COUNCIL
TO ARRANGE COLLECTION.
● Submerge all of the components into a cleaning
fluid compatible with the fluid being sprayed.
