LED lights
LED lights:
These lights serve several functions. They are the indicators to see if the system is
operating as it should or not.
LED 1
System
learning
Two flashes followed by 1 second pause = standby mode for
double gate.
Single flash followed by a 1 second pause = standby mode for a
single arm operation
Permanent glow = Gate learning process is incomplete.
LED 2
RF
Light is ON once the remote, key selector, or push button has
been activated.
LED 3
Photocells
Light is ON when photo beams fitted and signal is being sent.
LED 4
Photocells
Light is ON when photo beams fitted and signal is being sent.
Optional devices use standard network or telecom cable
Hint…check that the auto close is functioning to close the gate and not open before you
start connecting the optional devices! You may need to swap the motor cables around.
Installing wired keypad to Double gates: Positive red to the 12+ on the board (J2
terminal 1) and (-) negative black to the G (J2 terminal 2). For double swing gates
connect Com of the keypad to G on terminal 9 and D (short for double!) terminal 7.
Installing wired Button to Double gates: Connect Com of the button to G on
terminal 9 and D (short for double!) terminal 7. Also used for intercom or dial to open.
Installing wired keypad to a Single gate: Positive red to the 12+ on the board (J2
terminal 1) and negative black to the G (terminal 2). For single swing gate connect Com
of the keypad to G on terminal 9 and S (short for Single!) terminal 8. Also used for
intercom or dial to open.
Installing wired Button to a Single gate: Connect Com of the button to G on J2 Block
1 terminal 9 and S (short for Single!) terminal 8. Also used for intercom or dial to open.
Installing optional safety beams (recommended):
Sold as a pair, one with 5 connection points called the “Master board” and the one with 2
connection points called the “Slave board”.
Connect the slave board positive terminal to the 12+ block on the control board J2
(Block 1 terminal 1) and the slave negative terminal to the G (Block 1 terminal 2).
For the master board connect the positive and negative as above.
Now connect the normally closed terminal (NC) to FO1 (Block 1 terminal 3). Then
connect the common (COM) to G (Block 1 terminal 6).
You must now change the dip switch settings to the following:
SW2… Switch 1 (1.photo_1) and 2 (2.Photo_2) to the OFF.
