EasyIO FC
20 User R
eference v1.3
EasyIO FC-
20
enlarged
DIP switch Set
ting
DIP switch
number
Functions
Remarks
1
Protocol S
etting
On = Bacnet MS
TP
Off = Modus RTU
2
Serial Address
(Address 6
4)
MSB
3
Serial Address
(Address 3
2)
4
Serial Address
(Address 1
6)
5
Serial Address
(Address 8
)
6
Serial Address
(Address 4
)
7
Serial Address
(Address 2
)
8
Serial Address
(Address 1
)
LSB
117
9
11
