EasyIO FW Series – User Reference v3.0
17
Analog Output Connection
EasyIO FW series has Analog Output connections. Each Analog Output can only drive voltage.
The operating range for voltage mode is 0 – 10V.
**We DO NOT recommend you to drive a relay directly from UO 0-10V mode as it is not design for it
and will damaged the UO. **
Voltage: 0 – 10VDC , Min Impedance 2,000 Ohm.
