4 EATON EP Control for Heavy Duty Series 2 Piston Pumps Parts & Service 08-10-0002-EN-0901 September 2001
EP Control Kits
MODEL CODE INPUT VALVE ELECTRONIC
KIT NO. REFERENCE KIT DESCRIPTION SIGNAL ASSEMBLY MODULE VOLTAGE
9900040-000 EE EP Ctrl Kit HD Series 2 33/64: 1-6 V input 1-6 V 4993054-012 111520-016 12/24
9900042-000 EG EP Ctrl Kit HD Series 2 33/64: ±4-20 mA input ±4-20 mA 4993054-012 111520-020 12/24 V
9900043-000 EC EP Ctrl Kit HD Series 2 33/64: 12 V coils w/o electronics — 4993054-012 — 12 V
9900044-000 ED EP Ctrl Kit HD Series 2 33/64: 24 V coils w/o electronics — 4993054-024 — 24 V
990830-000 EP Crtl Electronic Module 1-6 V 1-6 V — 111520-016 —
990832-000 EP Crtl Electronic Module ±4-20 mA ±4-20 mA — 111520-020 —
Note: All kits using Eaton Electronic Modules use 12 V coils.
Parts
Parts List
ITEM PART NO. QTY. DESCRIPTION
1 111520-016 1 Electronic Module - 1-6 V Input - 12/24 V
1 111520-020 1 Electronic Module - ±4-20 mA Input - 12/24 V
2 101673-175 3 10-24 Button Head Cap Screw (1/8 hex key) - 1.75"
3 16045-203 3 #10 Lockwasher
4 95912-200 5 5/16"-18 Hex Head Cap Screw - 2.75"
5 111501-000 2 Solenoid Tube Subassembly*
6 114241-012 1 Solenoid Coil Subassembly - 12 V (includes two coils and wiring harness)
6 114241-024 1 Solenoid Coil Subassembly - 24 V (includes two coils and wiring harness)
7 4993054-012 1 Valve Assembly - (includes items 5 & 6 - 12 V Solenoid Coil & Tube Subassemblies)
7 4993054-024 1 Valve Assembly - (includes items 5 & 6 - 24 V Solenoid Coil & Tube Subassemblies)
8 110003-000 1 Control Valve Gasket
*Includes necessary O-Rings.
Electronic Module Mating Connector Kit
KIT NO. PART (QTY.) DELPHI PACKARD P/N
990762-000 Command Input Signal Connector (1) 1211 0293
Terminal (3) 1204 8074
Cable Seal (3) 1204 8086
Cavity Plug (1) 1205 9168
Secondary Lock (1) 1205 2845
Power Supply Connector (1) 1205 2641
Terminal (2) 1204 8074
Cable Seal (2) 1204 8086
Secondary Lock (1) 1205 2634
Recommended wire size: 16 - 18 AWG
Recommended cable diameter: 2.03 - 2.80 mm
Alternate reference source: Pioneer Standard Electronics 1-800-257-6613
www.pios.com
Solenoid Coil Mating Connector Kit
(not needed when using an Eaton Electronic Module)
KIT NO. PART (QTY.) DELPHI PACKARD P/N
9900023-000 Connector (1) 1218 6568
Terminal (4) 1204 8074
Cable Seal (4) 1204 8086
Secondary Lock (1) 1204 7948
Recommended wire size: 16 - 18 AWG
Recommended cable diameter: 2.03 - 2.80 mm
Alternate reference source: Pioneer Standard Electronics 1-800-257-6613
www.pios.com
Solenoid Connector Update Kit
KIT NO. PART (QTY.) DELPHI PACKARD P/N
9900045-000 Tool (1) 1209 4429
4-Pin Housing Connector (Female) (1) 1218 6568
4-Pin Housing Connector (Male) (1) 1218 6271
EP Control Connector Kits
