9EATON EP Control for Heavy Duty Series 2 Piston Pumps Parts & Service 08-10-0002-EN-0901 September 2001
Reassembly
Step 11
In most cases it will not be
necessary to remove the control
orifices that are staked in the pump
housing. Only remove if the orifice
size needs to be changed. The
orifice size is stamped on the flat
plate orifices in the pressure,
servo-1, and servo-2 ports.
Step 12
Clean the EP Control mounting
surface. Install a new control valve
gasket by aligning with screw and
porting holes.
Step 10
Remove and discard the control
valve gasket.
Repair & Service
To Next Page
