Input supply
line-to-line voltage [V]
UPS rating [kW]
30 40 50 80 100
400 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Rectifier and bypass
fuse [A]
63 80 100 160 200
Protective bonding cable
[mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
415 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Rectifier and bypass
fuse [A]
63 80 100 160 200
Protective bonding cable
[mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
440 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Rectifier and bypass
fuse [A]
63 80 100 160 200
Protective bonding cable
[mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
480 Phase cables [mm
2
] 1 x 10 1 x 25 1 x 35 1 x 70 1 x 95
Rectifier and bypass
fuse [A]
50 80 100 160 200
Protective bonding cable
[mm
2
]
1 x 10 1 x 16 1 x 16 1 x 35 1 x 50
690 Phase cables [mm
2
] 1 x 6 1 x 10 1 x 16 1 x 35 1 x 50
Rectifier and bypass
fuse [A]
40 50 63 100 125
Protective bonding cable
[mm
2
]
1 x 6 1 x 10 1 x 16 1 x 16 1 x 25
Table 8: Minimum recommended multi-core cable and fuse sizes for UPS output connec-
tion, 9PHD 30–100 kW UPS
Input supply
line-to-line voltage [V]
UPS rating [kW]
30 40 50 80 100
208 Phase cables [mm
2
] 1 x 50 1 x 70 1 x 95 1 x 185 1 x 240
Protective bonding ca-
ble [mm
2
]
1 x 25 1 x 35 1 x 50 1 x 95 1 x 120
230 Phase cables [mm
2
] 1 x 50 1 x 70 1 x 95 1 x 185 1 x 240
Protective bonding ca-
ble [mm
2
]
1 x 25 1 x 35 1 x 50 1 x 95 1 x 120
380 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 95 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 16 1 x 16 1 x 16 1 x 50 1 x 50
