Input supply
line-to-line voltage [V]
UPS rating [kW]
30 40 50 80 100
400 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
415 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
440 Phase cables [mm
2
] 1 x 16 1 x 25 1 x 35 1 x 70 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 16 1 x 16 1 x 16 1 x 35 1 x 50
480 Phase cables [mm
2
] 1 x 10 1 x 25 1 x 35 1 x 70 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 10 1 x 16 1 x 16 1 x 35 1 x 50
690 Phase cables [mm
2
] 1 x 6 1 x 10 1 x 16 1 x 35 1 x 95
Protective bonding ca-
ble [mm
2
]
1 x 6 1 x 10 1 x 16 1 x 16 1 x 50
Note: Note that power upgrading of the UPS is possible only if the sizing of
external cables is sufficient. Alternatively, external cabling must be upgraded
as well. The type of the fuses is gG.
Cable sizing is based on IEC 60364-5-52. Sizing is for installation method C
(wall installation) of PVC insulated copper wires. Conductor temperature: 70
°C, ambient temperature: 30 °C.
When using aluminium cables, check sizing recommendations from Eaton
product support.
Table 9: Rated and maximum currents for rated power and voltage
Rated
power [kW]
Rated
voltage [V]
Rectifier input Bypass input UPS output
Rated
current [A]
Maximum
current [A]
Rated
current [A]
Rated
current [A]
30 208 96 113 92 85
230 87 102 83 77
380 48 57 46 46
400 46 54 44 44
415 44 52 42 42
440 45 53 43 40
480 42 49 40 37
690 29 34 28 26
