BSPD SPDs for switchgear and power distribution panels
5.0 Specifications
Table 3. Specifications
Description Specification
Available system voltages
Three-phase Wye 120/208, 277/480 and 347/600
Three-phase Delta 240, 480 and 600
Input power frequency 50/60Hz
Maximum Continuous Operating Voltage (MCOV)
208Y, and 240D voltage/system type codes 150 L-N,150 L-G, 150 N-G, 300 L-L
480Y Voltage/system type code 320 L-N, 320 L-G, 320 N-G, 640 L-L
600Y Voltage/system type code 420 L-N, 420 L-G, 420 N-G, 840 L-L
480D Voltage/system type code 640 L-G, 640 L-L
600D Voltage/system type code 840 L-G, 840 L-L
Short-Circuit Current Rating (SCCR) 200kA
Nominal discharge current (I
n
) 20kA
Surge current capacity per phase (I
max
) 120kA, 200kA, 300kA and 400kA ratings available
SPD types
Type 1 (
Basic configuration, can also be used in Type 2 applications)
Type 2 (s tandard and s tandard with surge counter configurations)
Enclosure types NEMA 1, NEMA 4X
Ports 1
SPD Conductor length/gauge 48” (1.22m) 10AWG stranded copper
Form C contact relay (s
tandard and s tandard with surge counter configurations only)
Contact ratings 150Vac or 125Vdc, 1A maximum
Lead length/gauge 48 inches (1.22m) / 14AWG
Contact logic
Power ON, normal state; N.O. contact = OPEN, N.C. contact = CLOSED
Power OFF, fault state; N.O. contact = CLOSED, N.C. contact = OPEN
Power consumption
Basic configuration
208Y and 240D voltage/system type codes 0.5W
480Y and 480D voltage/system type codes 1.1W
600Y and 600D voltage/system type codes 1.3W
Standard and standard with surge counter configurations
208Y and 240D voltage/system type codes 0.6W
480Y, and 480D voltage/system type codes 1.7W
600Y and 600D voltage/system type codes 2.1W
Protection modes
Three-phase Delta; L-G, L-L
Three-phase Wye; L-N, L-G, N-G, L-L
Operating temperature / humidity -40 to +50°C (-40 to +122°F) / 5% to 95%, non-condensing
Operating altitude - ft (m) 16,000 (5000)
EMI/RFI filtering attenuation
Up to 50dB from 10kHz to 100MHz (s
tandard and s tandard with surge counter
configurations)
Weight - lbs (kg)
NEMA 1: 120kA-200kA - 6.8 (3.1), 30- 400kA -13.5 (6.1) NEMA 4X: 120-200kA - 14.6 (6.6),
300-400kA - 21.0 (9.5)
Agency information
-
Basic, standard and s tandard with surge counter configurations UL Listed 1449 3rd Edition
File E316410 Guide VCZA, CSA Certified Notice 516 File 243397
- Standard and s tandard with surge counter configurations are also UL Recognized 1283
5th Edition File E316410 Guide VCZA2, CSA Component Acceptance Std. C22.2
No. 8-M1986 File 243397
Seismic withstand capability Meets or exceeds the requirements specific to I.B.C. 2006, C.B.C 2007 and U.B.C Zone 4
Warranty 10 Years (see warranty statement 3A1502 for details at www.cooperbussmann.com/Surge)

Eaton Bussmann Series Specifications

General

Series	Bussmann series
Voltage Rating	Up to 600V AC/DC
Current Rating	Up to 600A
Interrupting Rating	Up to 200kA
Type	Disconnect Switch
Enclosure Type	NEMA 1, 3R
Standards	UL Listed, CSA Certified
