TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
23 Metering Forward
Demand
023 Power Factor at
Max Forward kVA
X.XX
(Date / Time shown)
0 NA NA NA NA NA
• This is the instantaneous power factor of the load at the first time when the maximum kVA demand occurred, since last
reset.
• Date and time of the occurrence of the highest maximum kVA demand is displayed.
• Note: This parameter is associated with the maximum kVA demand; therefore, it cannot be reset independent of that
parameter.
23
Metering Forward
Demand
023 Power Factor at
Min Forward kVA
X.XX
(Date / Time shown)
0 NA NA NA NA NA
• This is the instantaneous power factor of the load at the first time when the minimum kVA demand occurred (since last
reset).
• Date and time of the occurrence of the lowest minimum kVA demand is displayed.
• Note: This parameter is associated with the minimum kVA demand; therefore, it cannot be reset independent of that
parameter
024 Metering Forward
Demand
024 Forward
kVA Load High
XXXX.X kVA
(Date / Time shown)
0 NA 1 NA NA NA
• This is the highest value of the load kVA (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the highest kVA load is displayed.
24
Metering Forward
Demand
024 Forward
kVA Load Low
XXXX.X kVA
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load kW (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the lowest kVA load is displayed.
24
Metering Forward
Demand
024 Forward
kVA Load Present
XXXX.X kVA
0 NA NA NA NA NA
• This is the present value of the load kVA, as a demand value, according to the demand time interval at FC 46.
25 Metering Forward
Demand
025 Forward 0 NA 1 NA NA NA
• This is the highest value of the load kW (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the highest kW load is displayed.
25
Metering Forward
Demand
025 Forward
kW Load High
XXXX.X kW
(Date / Time shown)
0 NA 1 NA NA NA
• This is the lowest value of the load kW (since last reset), as a demand value, according to the demand time interval at
FC 46.
• Date and time of the occurrence of the lowest kW load is displayed.
42
