7
Relay Output Option Board
Typical Wiring
Durant
®
1
Terminal Designation
Relay
2
Relay
1
External
Power
6
5
4
3
2
1
Load
1
6
5
4
3
2
1
Contact Ratings
5 A @250 VAC or 30 VDC maximum
1
An RC surge suppressor is recommended across all inductive loads.
RS 485 Communication Option Board
Durant
®
1
485
+
485
-
Common
To Host Serial Port
WIRING cont.
