ELC Programming Manual
For more information visit: www.eaton.com MN05003003E
3-26
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
24 INC DINC

Increment
 



3 5
25 DEC DDEC

Decrement
 



3 5
26 WAND DAND

Logical AND
 



7 13
27 WOR DOR

Logical OR
 



7 13
28 WXOR DXOR

Exclusive XOR
 



7 13
29 NEG DNEG

Negative (2’s Compliment)
 



3 5
Rotation and Displacement
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
30 ROR DROR

Rotate Right
 



5 9
31 ROL DROL

Rotate Left
 



5 9
32 RCR DRCR

Rotate Right with Carry
 



5 9
33 RCL DRCL

Rotate Left with Carry
 



5 9
34 SFTR -

Bit Shift Right
 



9 -
35 SFTL -

Bit Shift Left
 



9 -
36 WSFR -

Word Shift Right -




9 -
37 WSFL -

Word Shift Left -




9 -
38 SFWR -

Shift Register Write -




7 -
39 SFRD -

Shift Register Read -




7 -
Data Operation
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
40 ZRST -

Zone Reset
 



5 -
41 DECO -

Decode
 



7 -
42 ENCO -

Encode
 



7 -
43 SUM DSUM

Sum of ON bits
 



5 9
44 BON DBON

Bit ON Test
 



7 13
45 MEAN DMEAN

Mean Value
 



7 13
46 ANS - - Alarm Set -




7 -
47 ANR -

Alarm Reset -




1 -
48 SQR DSQR

Square Root
 



5 9
49 FLT DFLT

Floating Point
    
5 9
