ELC Programming Manual
For more information visit: www.eaton.com MN05003003E
3-28
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
76 ASC - - ASCII code conversion -
11 -
77 PR - - Output ASCII code -
5 -
Serial I/O
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
78 FROM DFROM
Read special module CR data
9 17
79 TO DTO
Special module CR data write in
9 17
80 RS - - Serial data communication
9 -
81 PRUN DPRUN
Octal number system transmission -
5 9
82 ASCII -
Convert HEX to ASCII
7 -
83 HEX -
Convert ASCII to HEX
7 -
84 CCD -
Check sum -
7 -
85 VRRD -
Volume read -
-
5 -
86 VRSC -
Volume scale -
-
5 -
87 ABS DABS
Absolute value
3 5
88 PID DPID - PID calculation
9 17
Basic Instruction
Mnemonic Availability STEPS
API
16 bits 32 bits
P
Function
PB
B-PB
PC
PA
PH
M-PH
M-PA
PV
16 32
89 PLS - - Rising-edge output
3 -
90 LDP - - Rising-edge pulse
3 -
91 LDF - - Falling-edge pulse
3 -
92 ANDP - -
Serial connection of rising-edge
pulse
3 -
93 ANDF - - Serial connection falling-edge pulse
3 -
94 ORP - -
Parallel connection of rising-edge
pulse
3 -
95 ORF - -
Parallel connection of falling-edge
pulse
3 -
96 TMR - - Timer
4 -
97 CNT DCNT - Counter
4 6
98 INV - - Inverting operation
1 -
99 PLF - - Falling-edge output
3 -
