C. Remove the part.
D. Pull the plastic tab to remove the battery
block and replace it.
Mounting the new battery module
Carry out the above instructions in reverse order.
w To ensure safety and high performance, use only batteries supplied by EATON.
w Take care to firmly press together the two parts of the connector during remounting.
5. Maintenance
86-81700-00EN A02 - Page 23
