Eaton GridAdvisor Series II User Manual

Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
048 Current
Calibration
XXX.X mAmps
MilliAmp View Admin NA See Note 100.0 400.0
•The current which the control actually measures in mA, is displayed at FC 48.
•The control is designed for 200 mA as the rated CT secondary output current and will
meter to 800 mA with no loss of accuracy.
•To calibrate, this value is compared to a reference ammeter and, if different, is changed
to display the correct value.
•Note: A default calibration factor is programmed into non-volatile memory at the factory;
adjustments should not be necessary.
•See Section 8: Troubleshooting: Control calibration.
•In addition to the low and high limits, the user must enter a value that is within 5% of
the displayed value.
049 Tap Changer Type
Cooper QD8
--- View Modify NA
“-----”
(Invalid)
NA NA
•This function code identifies the tap-changer type. Changing this function code changes
the control’s sampling rate to accommodate varying tap-changer types.
•Options include: Eaton's Cooper Power series QD8; Eaton's Cooper Power series QD5; Eaton's
Cooper Power series QD3; Eaton's Cooper Power series Spring Drive; Eaton's Cooper Power
series Direct Drive; Siemens; General Electric; Howard; LTC Reinhausen; ITB, Toshiba, User
Defined.
050 System Calendar
and Clock
MM-DD-YYYY HH:MM:SS
--- View Modify NA See Note NA NA
•Editing is always in the format MM-DD-YYYY and with the 24 Hour clock.
•Note: The default is Jan. 1, 1970.
•Refer to Section 6: Control Features: Calendar/clock.
050 UTC Time Zone
GMT-05:00
--- View NA NA NA NA NA
•Used to set the time zone with respect to Greenwich Mean Time. The options include: GMT-
12:00 to GMT-01:00; Greenwich Mean Time; GMT+01:00 to GMT+13:00.
•This cannot be edited via the keypad; use of ProView NXG interface software is required
for editing.
051 Reverse
Set Voltage
XXX.X Volts
Volts View Modify NA 120.0 100.0 135.0
•The set voltage is the voltage level to which the control will regulate on the 120 V or
240 V base during reverse power flow.
•See FC 1 and Section 6: Control Features: Reverse power operation.
•If an alternate configuration is active, the fourth LCD line displays which one is active,
e.g. (ALT CONFIG 1).
•If FC 148 Nominal Load Voltage is set to 240 Volts, limits are expanded (doubled).
•If FC 148 is set to System Line Voltage, this setting must be set in terms of the system
line voltage. For example, on a 7200 V system, with a desired set voltage 1% above the
nominal voltage, the setting would be 7272.
63
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
