HMi VU Series Instruction Leaflet
HMIVU07CUNBE (Rear View)
D
E
F
G
A
H
B
I
C
J
A Power Input Terminal F USB Host
B COM2 and COM3
(Note1)
G USB Slave
C COM1 H System Button
D Battery Cover I Ethernet Port
E Memory Card Slot J Audio Output Port
NOTE
1. Refer to the Pin Definition for Communications section for simultaneous use of COM2 and COM3.
