HMi VU Series Instruction Leaflet
HMIVU08CUNBE (Front View)
D
B
A
C
A
: Power LED Indicator
Lights in green when power is applied.
B
: Operation LED Indicator (Blue)
(Note1)
The operation LED indicator blinks in blue when communicating or accessing data
C
: Alarm LED Indicator (Red)
The alarm LED indicator blinks in red when one of the alarms is on.
D Touch Screen / Display
NOTE
1. The function for which the Blue LED indicator lights can be selected in HMiSoft.
