HMi VU Series Instruction Leaflet
HMIVU08CUNBE (Rear View)
I
H
G
F
E
D
C
A
B
A Power Input Terminal
B
COM3
(Two LED indicate Read or Write status during the communication process.)
C
COM2
(Two LED indicate Read or Write status during the communication process.)
D COM1
E USB Slave
F Ethernet Port
G USB Host
H Audio Output Port
I Memory Card Slot / Battery Cover
