Magnum PXR and Power Defense SB low
voltage power circuit breakers user manual
EATON www.eaton.com
Table 3. Basic circuit breaker weights
(lifting and support reference only)
Breaker
model
a
Weight (lb)
Fixed Drawout
Universal
cassette
Three-
pole
Four-
pole
Three-
pole
Four-
pole
Three-
pole
Four-
pole
MPN-408 95 120 107 136 61 70
MPN-508 95 120 107 136 61 70
MPN-608 95 120 107 136 61 70
MPN-C08 95 120 108 136 61 70
MPS-408 114 141 130 161 117 123
MPS-508 118 146 138 172 117 123
MPS-608 118 146 138 172 117 123
MPS-808 128 160 155 194 117 123
MPS-C08 128 160 155 194 117 123
MPN-412 95 120 107 136 61 70
MPN-512 95 120 107 136 61 70
MPN-612 95 120 107 136 61 70
MPN-C12 95 120 108 136 61 70
MPS-512 118 146 138 172 117 123
MPS-612 118 146 138 172 117 123
MPS-812 128 160 155 194 117 123
MPS-C12 128 160 155 194 117 123
MPN-416 95 120 107 136 61 70
MPN-516 95 120 107 136 61 70
MPN-616 95 120 107 136 61 70
MPN-C16 95 120 108 136 61 70
MPS-516 118 146 138 172 117 123
MPS-616 118 146 138 172 117 123
MPS-816 128 160 155 194 117 123
MPS-C16 128 160 155 194 117 123
MPN-620 95 120 107 136 61 70
MPN-C20 95 120 107 136 61 70
MPS-620 128 160 155 194 117 123
MPS-820 128 160 155 194 117 123
MPS-C20 128 160 155 194 117 123
Table 33. Basic circuit breaker weights (continued)
Breaker
model
Weight (lb)
Fixed Drawout Universal cassette
Three-
pole
Four-
pole
Three-
pole
Four-
pole
Three-
pole
Four-
pole
MPS-625 150 190 189 240 123 150
MPS-825 150 190 189 240 123 150
MPS-C25 150 190 189 240 123 150
MPS-630 150 190 189 240 123 150
MPS-830 150 190 189 240 123 150
MPS-C30 150 190 189 240 123 150
MPS-632 150 190 189 240 123 150
MPS-832 150 190 189 240 123 150
MPS-C32 150 190 189 240 123 150
MPN-640, 4N, 4A 177 225 214 271 106 125
MPN-840, 4N, 4A 177 225 214 271 106 125
MPN-C40, 4N, 4A 177 225 214 271 106 125
MPS-840, 4N, 4A 237 319 303 366 199 250
MPS-C40, 4N, 4A 237 319 303 366 199 250
MPN-65N 177 225 295 393 106 125
MPN-85N 177 225 295 393 106 125
MPN-C5N 177 225 295 393 106 125
MPS-850, 5N, 5A 276 360 343 441 212 266
MPS-C50, 5N, 5A 276 360 343 441 212 266
MPS-860, 6N, 6A 276 360 343 441 212 266
MPS-C60, 6N, 6A 276 360 343 441 212 266
a
For Power Defense SB breakers, breaker model will begin with SPS or SPN. Listed
weights are applicable for both product lines.
Circuit breaker inspection
All circuit breakers, once removed from their shipping containers,
should be visually inspected for any obvious damage.
The current rating label that is applied to the battery cover on the trip
unit frame should match the current rating programmed into the trip
unit. Check to make sure that this match exists. The circuit breaker
current rating (I
n
) can be easily changed as described in Section 7 of
MN013015EN.
