Eaton Magnum PXR User Manual

7
User Manual MN013016EN
Effective July 2022
Magnum PXR and Power Defense SB low
voltage power circuit breakers user manual
EATON www.eaton.com
Table 1. Magnum PXR ratings at 240, 480, 600 V
Maximum
amperes
Breaker
designation
Interrupting
rating
Short-time
rating
800 MPN-408 42 kA 42 kA
MPN-508 50 kA 50 kA
MPN-608 65 kA 65 kA
MPN-C08 100 kA (240 V, 480 V)
a
65 kA
MPS-408 42 kA 42 kA
MPS-508 50 kA 50 kA
MPS-608 65 kA 65 kA
MPS-808 85 kA 85 kA
MPS-C08 100 kA 85 kA
1200 MPN-412 42 kA 42 kA
MPN-512 50 kA 50 kA
MPN-612 65 kA 65 kA
MPN-C12 100 kA (240 V, 480 V)
a
65 kA
MPS-512 50 kA 50 kA
MPS-612 65 kA 65 kA
MPS-812 85 kA 85 kA
MPS-C12 100 kA 85 kA
1600 MPN-416 42 kA 42 kA
MPN-516 50 kA 50 kA
MPN-616 65 kA 65 kA
MPN-C16 100 kA (240 V, 480 V)
a
65 kA
MPS-516 50 kA 50 kA
MPS-616 65 kA 65 kA
MPS-816 85 kA 85 kA
MPS-C16 100 kA 85 kA
2000 MPN-620 65 kA 65 kA
MPN-C20 100 kA (240 V, 480 V)
a
65 kA
MPS-620 65 kA 65 kA
MPS-820 85 kA 85 kA
MPS-C20 100 kA 85 kA
2500 MPS-625 65 kA 65 kA
MPS-825 85 kA 85 kA
MPS-C25 100 kA 85 kA
3000 MPS-630 65 kA 65 kA
MPS-830 85 kA 85 kA
MPS-C30 100 kA 85 kA
3200 MPS-632 65 kA 65 kA
MPS-832 85 kA 85 kA
MPS-C32 100 kA 85 kA
4000 MPN-640, 4N, 4A 65 kA 65 kA
MPN-840, 4N, 4A 85 kA
a
85 kA
MPN-C40, 4N, 4A 100 kA
a
100 kA
MPS-840, 4N, 4A 85 kA 85 kA
MPS-C40, 4N, 4A 100 kA 100 kA
5000 MPN-65N 65 kA 65 kA
MPN-85N 85 kA (240 V, 480 V)
a
85 kA
MPN-C5N 100 kA (240 V, 480 V)
a
100 kA
MPS-850, 5N, 5A 85 kA 85 kA
MPS-C50, 5N, 5A 100 kA 100 kA
6000 MPS-860, 6N, 6A 85 kA 85 kA
MPS-C60, 6N, 6A 100 kA 100 kA
a
65kA @ 600V
Table 2. Power Defense SB ratings at 240, 480, and 600V
Maximum
amperes
Breaker
designation
Interrupting
rating
Short-time
rating
800 SPN-408 42 kA 22 kA
SPN-508 50 kA 22 kA
SPN-608 65 kA 22 kA
SPN-C08 100 kA (240 V, 480 V)
a
22 kA
SPS-408 42 kA 22 kA
SPS-508 50 kA 22 kA
SPS-608 65 kA 22 kA
SPS-808 85 kA 22 kA
SPS-C08 100 kA 22 kA
1200 SPN-412 42 kA 25 kA
SPN-512 50 kA 25 kA
SPN-612 65 kA 25 kA
SPN-C12 100 kA (240 V, 480 V)
a
25 kA
SPS-512 50 kA 25 kA
SPS-612 65 kA 25 kA
SPS-812 85 kA 25 kA
SPS-C12 100 kA 25 kA
1600 SPN-416 42 kA 30 kA
SPN-516 50 kA 30 kA
SPN-616 65 kA 30 kA
SPN-C16 100 kA (240 V, 480 V)
a
30 kA
SPS-516 50 kA 30 kA
SPS-616 65 kA 30 kA
SPS-816 85 kA 30 kA
SPS-C16 100 kA 30 kA
2000 SPN-620 65 kA 35 kA
SPN-C20 100 kA (240 V, 480 V)
a
35 kA
SPS-620 65 kA 35 kA
SPS-820 85 kA 35 kA
SPS-C20 100 kA 35 kA
2500 SPS-625 65 kA 42 kA
SPS-825 85 kA 42 kA
SPS-C25 100 kA 42 kA
3000 SPS-630 65 kA 50 kA
SPS-830 85 kA 50 kA
SPS-C30 100 kA 50 kA
3200 SPS-632 65 kA 50 kA
SPS-832 85 kA 50 kA
SPS-C32 100 kA 50 kA
4000 SPN-640, 4N, 4A 65 kA 65 kA
SPN-840, 4N, 4A 85 kA (240 V, 480 V)
a
65 kA
SPN-C40, 4N, 4A 100 kA (240 V, 480 V)
a
65 kA
SPS-840, 4N, 4A 85 kA 65 kA
SPS-C40, 4N, 4A 100 kA 65 kA
5000 SPN-65N 65 kA 65 kA
SPN-85N 85 kA (240 V, 480 V)
a
65 kA
SPN-C5N 100 kA (240 V, 480 V)
a
65 kA
SPS-850, 5N, 5A 85 kA 85 kA
SPS-C50, 5N, 5A 100 kA 85 kA
a
65kA @ 600V
