Eaton NRX Series Instruction Manual

7
Section 1: Introduction
Series NRX with PXR – Type NF Low Voltage Power (Air) Circuit Breaker Instruction Manual MN013001EN May 2015 www.eaton.com
Figure 3. Typical NRX Type NF Drawout Circuit Breaker (Front and Rear Views).
ote:N Refer to Figure 6 for more visual details of front cover.
1. Arc Chute Cover
2. Primary Shroud
3. Lifting Handle
4. Front Cover
5. Drawout Wheels
6. Primary Finger Cluster
7. Secondary Contacts
8. Levering Mechanism
1
3
5
4
2
1
5
4
3
8
6
7
2
