Section 1: Introduction
Series NRX with PXR – Type NF Low Voltage Power (Air) Circuit Breaker Instruction Manual MN013001EN May 2015 www.eaton.com
Figure 5. Typical NRX Type NF Fixed Circuit Breaker (Rear Connected Type).
ote:N Refer to Figure 6 for more visual details of front cover.
1. Arc Hood Baffle
2. Arc Hood
3. Secondary Contacts
4. Front Cover
5. Secondary Wiring Contact Points
6. Typical Rear Bus Adapter (Horizontally Mounted to
Primary Terminal Pad)
7. Typical Rear Bus Adapter (Vertically Mounted to
Primary Terminal Pad)
1
2
6
7
4
3
2
1
5
