Section 1: Introduction
Series NRX with PXR – Type NF Low Voltage Power (Air) Circuit Breaker Instruction Manual MN013001EN May 2015 www.eaton.com
Figure 6. Typical NRX Type NF Drawout Circuit Breaker Front Cover.
1. Contact Status
2. Spring Status
3. Charging Handle
4. Nameplate
5. Manual ON
6. Operations Counter
7. Position Indicator
8. Levering Access Door
9. Frame Rating Module
10. FRM Battery Cover
11. Manual OFF
12. USB and Aux. Power Ports
13. Pop-out Trip Flag
14. Trip Unit
15. OFF Key Lock
16. l
n
Rating - LCD Display on Trip Unit
1 7. l
n
Rating - FRM Battery Cover
ote:N The l
n
Rating on the LCD and
FRM Battery Cover should
ALWAYS agree.
ote:N Frame Rating Module should
NOT be removed.
15
12
6
5
4
3
2
1
13
7
8
11
10
17
14
16
12
9
