Eaton ON-LINE Series User Manual

6
Model
3C-10000F 3C-10000FL C-20000FL
Dimensions (W x D x H) (mm) 607× 300× 820 607× 325× 936
Net Weight (Kg) 136 81 131
Power Rating
Apparent power (KVA)/Active
power (KW)
10kVA/
8kW
20kVA/
16kW
Input
Voltage range 220VAC (-15%/+25%)
Current*
55A.max 110A.max
Frequency range
60Hz(+/-4Hz)
Power factor
0.99
Output
Voltage*
220(adjustable according to customer requirements)
Stability
±1%
Frequency
56Hz~64Hz (line mode, synchronize with line)
60Hz±0.05 (battery mode)
Power factor
0.8
Overload capacity
105%~125%: transfer to bypass after 1 min;
125%~135%: transfer to bypass after 30 seconds;
>135%: transfer to bypass after 0.1 second;
Distortion
THD<2% (full linear load)
Battery (the battery life reduce quickly under high temperature)
Backup time
> 5 mins(7000W)
Charge time
7 hours to 90%
EMC
EMI CNS 14757-2(C3)
EMS
ESD IEC61000-4-2 Level 4
RS IEC61000-4-3 Level 3
EFT IEC61000-4-4 Level 4
Surge IEC61000-4-5 Level 4
Caution: This product for commercial and industrial application in the second
environment installation restrictions or additional measures may be needed to prevent
disturbances.
Operation temperature 0°C~40°C
Storage temperature -25°C~55°C
Humidity 20%~90% (no condensation)
Altitude <1000m
