S811+ Operating Configuration
36 S811+ Soft Starter MN03900001E—November 2012
Fault Trip/Fault Warning/Disable Options
The S811+ has a comprehensive array of protection parameters. Selected Protection Parameters
have options to be set to a Fault Trip, Fault Warning, or disabled. Disabling fault protections is not
recommended.
Fault Code Options
Code Description Fault Options
1 Firmware incompatible Fault Trip, Fault Warning, Disable
3 Internal Com fault Fault Trip
4 Low Control V Fault Trip
5 Pole Overtemp Fault Trip, Fault Warning, Disable
6 PhaseLoss Fault Trip, Fault Warning, Disable
7 Phase Imbalance Fault Trip, Fault Warning, Disable
9 Underload Fault Trip, Fault Warning, Disable
10 Overcurrent(contactor)Jam disabled Fault Trip
11 Jam Fault Trip, Fault Warning, Disable
13 Bypass dropout Fault Trip, Fault Warning, Disable
14 Overload Fault Trip, Fault Warning, Disable
18 Inst I overcurrent Fault Trip
32 Internal NV error Fault Trip
36 ComLoss Stop fault Fault Trip
38 Temperature sensor fault Fault Trip, Fault Warning, Disable
39 Internal CPU fault Fault Trip
40 Motor Low Power Fault Trip, Fault Warning, Disable
41 Motor High Power Fault Trip, Fault Warning, Disable
42 UnderVoltage Fault Trip, Fault Warning, Disable
43 OverVoltage Fault Trip, Fault Warning, Disable
44 Phase Reversal Fault Fault Trip, Fault Warning, Disable
54 E-Stop Fault Trip
55 MotorControl Device missing Fault Trip
56 Internal Com2 fault Fault Trip
57 Internal Fault Fault Trip
58 SCR Not Firing Fault Trip, Fault Warning, Disable
59 Shorted SCR Fault Trip, Fault Warning, Disable
60 SCR Overcurrent (Stall disabled) Fault Trip
61 Mains AC V Lost Fault Trip
63 Motor Stall Fault Fault Trip, Fault Warning, Disable
64 V Zero cross Fault Trip
65 Analog Input Out of range (high) Fault Trip, Fault Warning, Disable
66 Analog Input Out of range (low) Fault Trip, Fault Warning, Disable
71 Analog Input Overdrive Fault Trip, Fault Warning, Disable
72 External trip/warning Fault Trip, Fault Warning, Disable
73 Motor Load Disconnect Fault Trip
74 Line Frequency (high) Fault Trip, Fault Warning, Disable
75 Line Frequency (low) Fault Trip, Fault Warning, Disable
76 Auto Reset Limit Fault Trip
