STEP 4 (Continued)
Drive Control Parameters — M1
➔
G1.4

Parameter value can only be changed after the drive has been stopped.
Prohibit Frequencies — M1 ➔ G1.5
Code Parameter Min. Max. Unit Default Cust ID Note
P1.4.1 Ramp 1
shape
0.0 10.0 s 0.0 500 0 = Linear
>0 = S-curve ramp
time
P1.4.2 Ramp 2
shape
0.0 10.0 s 0.0 501 0 = Linear
>0 = S-curve ramp
time
P1.4.3 Acceleration
time 2
0.1 3000.0 s 10.0 502
P1.4.4 Deceleration
time 2
0.1 3000.0 s 10.0 503
P1.4.5

Brake
chopper
0 4 0 504 0 = Disabled
1 = Used when
running
2 = External brake
chopper
3 = Used when
stopped/
running
4 = Used when
running (no
testing)
P1.4.6 Start function 0 1 0 505 0 = Ramp
1 = Flying start
P1.4.7 Stop function 0 3 1 506 0 = Coasting
1 = Ramp
2 = Ramp+Run
enable coast
3 = Coast+Run
enable ramp
P1.4.8 DC braking
current
0.00 I
L
A 0.7 x I
H
507
P1.4.9 DC braking
time at stop
0.00 600.00 s 0.00 508 0 = DC brake is off
at stop
P1.4.10 Frequency to
start DC
braking
during
ramp stop
0.10 10.00 Hz 1.50 515
P1.4.11 DC braking
time at start
0.00 600.00 s 0.00 516 0 = DC brake is off
at start
P1.4.12 Flux brake 0 1 0 520 0 = Off
1 = On
P1.4.13 Flux braking
current
0.1
x I
H
I
L
AI
H
519
Code Parameter Min. Max. Unit Default Cust ID Note
P1.5.1 Skip frequency
range 1 low
limit
0.00 Par.
1.5.2
Hz 0.00 509
P1.5.2 Skip frequency
range 1 high
limit
0.00 Par.
1.1.2
Hz 0.0 510 0 = Skip frequency
range 1 not
used
P1.5.3 Skip frequency
acc./dec. ramp
0.1 10.0 1.0 518
