22
Figure 13c. DG4S4-01-50 Pilot Valve, Sectional View
1/2 (NTPF) Thread
Connection
Manual Override Plunger
Wet Armature (Standard)
Push Pin
Terminal Box
Body
End Cover (“A” “B”,
or “F” Models)
Manual Override
Plunger
Wet Armature Solenoid
Pilot Spool
Solenoid Coil
Core Tube
“C” Models
Solenoid “A” Missing
Figure 13b. DG4S4-W-50 Pilot Valve, Sectional View
Figure 13a. DG4V-3-40 Pilot Valve, Sectional View
“C” Models
“B” Models
Solenoid “A”Solenoid “B”
Manual Override
Plunger
Pilot Spool
