Section IX – Internal Body Passages & Plug Locations
Two stage directional valves can be converted to different
operational modes, i.e., internal/external, pilot pressure or
drain, fast response, etc. To accomplish this, internal plugs
must be removed or added within the main stage body
passages.
Table 8 is a list of basic models with the incorporated
operational mode changes. Each model is referenced to a
particular figure. The figures illustrate internal passages and
plug locations.
Operational Mode Change
(Reference model code, Table 2)
* - Standard
X - Fast response option
E - External pilot pressure
CAUTION
DO NOT change internal plugs within main
stage body unless power is off and system
pressure is relieved.
K/R/S - Integral check valve
T - Internal pilot drain
Basic Model Description
DG5S4-04**-*-40
DG5S4-04**X-*-40
DG5S4-04**-E-*-40
DG5S4-04**X-E-*-40
DG5S4-04**-K/R/S-*-40
DG5S4-04**-E-K/R/S-*-40
DG5S4-04**-X-K/R/S-*-40
DG5S4-04**-X-E-K/R/S-*-40
DG5S4-04**-T-*-40
DG5S4-06**-*-51
DG5S4-06**X-*-51
DG5S4-06**-E-*-51
DG5S4-06**X-E-51
DG5S4-06**-K/R-*-51
DG5S4-06**-E-K/R-*-51
DG5S4-06**X-K/R-*-51
DG5S4-06**X-E-K/R-*-51
DG5S4-06**-T-*-51
DG5S4-H06**-*-51
DG5S4-H06**X-*-51
DG5S4-H06**-E-*-51
DG5S4-H06**X-E-*-51
DG5S4-H06**-K/R/S-*-51
DG5S4-H06**-E-K/R/S-*-51
DG5S4-H06**X-K/R/S-*-51
DG5S4-H06**X-E-K/R/S-*-51
Reference
Table 8. Internal Passages & Plug Tabulation
Figure 23a
Figure 23b
Figure 23c
Figure 24a
Figure 24b
Figure 24c
Figure 25a
Figure 25b
DG5S4-H06**-T-*-51
DG5S4-10**-*-51/53
DG5S4-10**X-*-51/53
DG5S4-10**-E-*-51/53
DG5S4-10**X-E-*-51/53
DG5S4-10**-K/R/S-*-51/53
DG5S4-10**-E-K/R/S-*-51/53
DG5S4-10**X-K/R/S-*-51/53
DG5S4-10**X-E-K/R/S-*-51/53
DG5S4-10**-T-*-51/53
DG5S-(H)8**-*-10/20
DG5S-(H)8**X-*-10/20
DG5S-(H)8**-E-*-10/20
DG5S-(H)8**X-E-*-10/20
DG5S-(H)8**-K/R/S-*-10/20
DG5S-(H)8**-E-K/R/S-*-10/20
DG5S-(H)8**X-K/R/S-*-10/20
DG5S-(H)8**X-E-K/R/S-*-10/20
DG5S-(H)8**-T-10/20
DG5S4-H06*D-51
DG5S-8-*D-*-10
DG5S4-06*D-*-51
DG5S4-10*D-*-51/53
Figure 25c
Figure 26a
Figure 26b
Figure 27a
Figure 27b
Figure 27c
Figure 24a
(Internal plug
locations only)
Figure 26c
Basic Model Description Reference
