EBARA TH Series - TH Frame-Mounted Pump Assembly

17
Rev10/2018
Operating, Installation, and Maintenance
TH Assembly Instruction (Continued)
Pump Assembly – TH Frame Mounted
Step 1
 
Heatthebearings(item849)toperformtheassemblyontheshaft
(item031).
Note: If possible, we recommend using an induction heater to facilitate
assemblyofbearings.

Step 2






Gasket 

Placethegaskets(item117)inthebearingcover(item845).
*Donotuseanyadhesivetypetoplacethegasket(item117).

Step 3

Install the shaft (item 031) with the bearings (item 849) into the
bearinghousing(item051)accordingtheillustration.
Usesoftfacehammertoassemble.

Step 4


Attachthebearingcovers(item845)andfastenthehexheadbolts
(item120‐3).

Step 5


FixO‐ring(item115)atcasecover(item011).Use grease toholdthe
O‐ringinplace.Donot useany kindofadhesive,thisshouldcause
chemicaldamageatrubber/elastomer.

