Operating, Installation, and Maintenance
TH Assembly Instruction (Continued)
Pump Assembly – TH Frame Mounted
Step 6

Insert the stationary part of mechanical seal (item 696) into case
cover(item011)usinggreaseoranothertypeoflubricant.Useasoft
facetooltoavoiddamages.Afterthestationarypartisinplace, clean
thefacewithanalcoholwipe.

Step 7



Usehexheadbolts(item120‐1)tofixthecasecover(item011)to
bearinghousing(item051).

Step 8



Place the rotating part of the mechanical seal on the shaft sleeve
(item042),centringthewashertotheimpellerside.

Step 9 


Lubricatetherotatingpartwithgrease tofacilitate assembly.

Step 10


Placetheshaftsleeve(item042)andO‐ring(item115‐2) ontheshaft
(item031).

