10． Specifications
3.2inch IPS screen
24V/36V/48V battery supply
Rated operating current : 40mA
Max operating current : 100mA (36V battery, with USB equipment changed)
USB changing port : 5V 500mA
Off leakage current < 1uA
Max output current to controller : 100mA
Operating temperature : -20～70℃, Storage temperature : -30～80℃
Product shell is ABS, transparent window is made with high strength Acrylic.
Dimensions : host/L92mm*W60mm*H14mm
11． Dimensions & Material
Product shell is ABS, transparent window is made with high strength Acrylic.
Dimensions : host/L92mm*W60mm*H14mm
