Clean Channel:
Input Impedance: Parallel mode 1.5 Mohms // 44 pF
Serial mode 10 Mohms // 22 pF
Gain: Gain Range min/max -oo/+30 dB
Gain Peak LED +10 d Bv
Frequency Response +0/-3 dB 20-20.000 Hz
Character: Filter Type Shelving High/Low Pass
Gain: Lo +6 dB @ 80 Hz
Mid -2 dB @ 900 Hz
Hi +3 dB @ 7.5 kHz
Bright: Filter Type Shelving.
Gain: +10 dB @ 10 kHz
Filter Section:
Bass Filter: Type 12 dB/oct. Shelving.
Gain Range +/- 18 dB @ 60 Hz
Mid Filter: Type Bandpass Filter.
Freq Range 50 - 5.000 Hz.
Q - Boost 0.5 - 1.3.
Q - Cut 0.5 - >5.
Gain Range +/- 12-15 dB
Treble Filter: Type Shelving.
Gain Range +/- 18 dB @ 8 kHz
COMP/LIMIT: Comp Gain 0 dB
Attenuation max 24 dB
Compression Ratio max 3:1
Attack (80%) typ <10 ms
Release (80%) typ 100 ms
Drive Channel:
Input Impedance: 1.8 Mohms // 22 pF
Drive: Gain Range 40 dB
Drive Engines:
Lo: Type 2nd harmonics soft
Hi: Type Symmetrical 2-stage with
+18 dB gain
Type Switch: Thin/Normal/Deep Pre Drive EQ
Filter Section:
Tone Filter: Type 6 dB/oct. Low Pass.
Frequency Range 700 - 20k Hz
Mid Filter: Type Bandpass Filter.
Frequency Range 100 - 4.500 Hz.
Q 1.2
Gain Range +/- 15 dB
Common Features:
Effects Loop: Loop Signal Level nominal -10 dBv
Gain Unity (1:1)
Output Impedance <10 0 oh ms
Input Impedance >200 kohms // 22 pF
Phones Out: Recommended Imp. 32 - 200 ohms
Aux Input: Input Impedance 20 kohms
Nominal Level -10 dBv
Output: Output Impedance <1 kohms
Signal Level nominal 0 dBv
Balanced Outputs: Output Level nominal -20dBv
XLR Connections 1-GND, 2-Hot, 3-Cold
Options Pre/Post EQ, L/R Ch.
in stereo mode
Auxiliary Info:
Power Requirements Idle 450mA @9V.
Max 750mA @9V
(with headphones at
max output level)
Dimensions (WxDxH): max 168 x 124 x 53 mm /
6.6” x 4.9” x 2.1”
Weight: 660 g ( 1.5 lbs.)
Specifications are subject to change without notice.
TECHNICAL SPECIFICATIONS - MICRO BASS 3
