8. Antenna Type
8.1 Antenna recommendation
The antenna plays an important role in the communication process. The inferior antenna often has a great impact on the
communication system. Therefore, we recommend some antennas that support our wireless modules and have excellent
performance and reasonable price.
Product
Type
Frequency
Hz
Interface
Gain
dBi
Size
Feeder
Features
TX433-NP-4310
Soft PCB antenna
433M
SMA-J
2
43.8*9.5mm
-
Built-in flexible FPC soft
antenna
TX433-JW-5
Rubber antenna
433M
SMA-J
2
50mm
-
Flexible, Omnidirectional
TX433-JWG-7
Rubber antenna
433M
SMA-J
2.5
75mm
-
Flexible, Omnidirectional
TX433-JK-20
Rubber antenna
433M
SMA-J
3
210mm
-
Flexible, Omnidirectional
TX433-JK-11
Rubber antenna
433M
SMA-J
2.5
110mm
-
Flexible, Omnidirectional
TX433-XP-200
Sucker antenna
433M
SMA-J
4
19cm
200cm
High Gain
TX433-XP-100
Sucker antenna
433M
SMA-J
3.5
18.5cm
100cm
High Gain
TX433-XPH-300
Sucker antenna
433M
SMA-J
6
96.5cm
300cm
High Gain
TX433-JZG-6
Rubber antenna
433M
SMA-J
2.5
52mm
-
Ultra short straight，
Omnidirectional
TX433-JZ-5
Rubber antenna
433M
SMA-J
2
52mm
-
Ultra short straight，
Omnidirectional
TX490-XP-100
Sucker antenna
490M
SMA-J
50
12cm
100cm
High Gain
TX490-JZ-5
Rubber antenna
490M
SMA-J
50
50mm
-
Ultra short straight
，
Omnidirectional
