Ebyte E220-900T30D User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. E220-900T30D User Manual
Copyright ©2012–2020, Chengdu Ebyte Electronic Technology Co.,Ltd.
17
8. Configuration Instruction on Computer
 The following figure shows the display interface of the E220-900T30D configuration host computer. The user can switch to the
command mode through M0 and M1, and quickly configure and read the parameters on the host computer.
 In the configuration of the host computer, the module address, frequency channel, network ID, and key are all displayed in
decimal mode; the value range of each parameter:
Network address：0～65535
Frequency channel：0～83
Key
：
0
～
65535
