3.4 LED Indicator Description
Label
Color
Explanation
PWR
Red
Power indicator
STATE
Green
Blinking slowly, connecting to the server
Fast blinking, waiting for network cable
or waiting for dynamic IP acquisition
Steady on, the server is connected
DATA
Yellow
Blinking: Server interacts with serial port
data
【Note】
Indicator status during firmware upgrade:
Waiting for the upgrade (host computer, serial port), STATE and TX/RX flash alternately, if the upgrade
package is not sent within 3s, the upgrade wait is exited;
Upgrading, STATE and TX/RX flash alternately slowly;
3.5 Serial port description
The serial port supports the following parameter configurations:
Project
Parameters
Baud rate
1200，2400，4800，9600，19200，
38400，57600，115200，230400
Data bits
8
Check bit
NONE、ODD、EVEN
Stop bit
1、2
