10.Connection diagram in test and practical application
11.related product
Product mode
Interf
ace
type
FrequencyMHz
Powe
r
dBm
Dista
nce
km
Features
E95-DTU(400SL22-485)
RS48
5
410.125 ～ 493.125
22
5
A new generation of LoRa, rail type, RS485,
E90-DTU SL series interoperability, DC
power supply
E95-DTU(400SL22-232)
RS23
2
410.125 ～ 493.125
22
5
New generation LoRa, rail type, RS232,
E90-DTU SL series interoperability, DC
power supply
E95-DTU(400SL30-485)
RS48
5
410.125 ～ 493.125
30
10
A new generation of LoRa, rail type, RS485,
E90-DTU SL series interoperability, DC
power supply
E95-DTU(400SL30-232)
RS23
2
410.125 ～ 493.125
30
10
New generation LoRa, rail type, RS232,
E90-DTU SL series interoperability, DC
power supply
E95-DTU(400SL22P-48
5)
RS48
5
410.125 ～ 493.125
22
5
New generation LoRa, rail type, RS232,
E90-DTU SL series interoperability, high
protection, DC power supply
E95-DTU(400SL22P-23
2)
RS23
2
410.125 ～ 493.125
22
5
New generation LoRa, rail type, RS485,
E90-DTU L series interoperability, high
protection, DC power supply
