POWER PRUNER
OPERATOR'S MANUAL
13A
SPECIFICATIONS
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication, but are subject
to change without notice. Illustrations may include optional equipment and accessories, and may not include all standard equipment.
MODEL PPSR-2122 PPSR-2433
Length 112.1 cm (44.125 in.) 142.9 cm (56.25 in.)
Width
22.2 cm (8.75 in.)
Height
22.9 cm (9.0 in.)
Weight (dry) 4.7 kg (10.3 lb.) 5.0 kg (10.9 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.268 in.) 34.0 mm (1.34 in.)
Stroke
26.0 mm (1.04 in.)
Displacement 21.2 cc (1.29 cu. in.) 23.6 cc (1.44 cu. in.)
Exhaust System Spark Arrestor Muffler
Carburetor Diaphragm, w/primer bulb
Ignition System CDI (capacitor discharge ignition)
Spark Plug NGK BPM-7A Gap 0.65 mm (0.026 in.) NGK BPM-7Y Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.4 lit. (14.0 US fl. oz.)
Recoil Starter System Automatic Recoil Starter
Clutch Centrifugal Type
Sprocket Type
6 tooth spur, 9.53 mm (3/8 inch) pitch
Shaft Tube Assembly
22.3 mm Dia. Polished Aluminum Tube - 1/4 in. Flexible
Gear Case Ratio 1.5:1
Oiling System Automatic
Chain Oil Capacity 225 ml (7.6 oz.)
Handles Right hand grip w/throttle trigger and throttle trigger lockout / Left hand loop w/hand guard
Idle Speed (RPM) 2600 - 3100
Wide Open Throttle Speed (RPM) 9000 - 11000 11000 - 12000
Guide Bar and Saw Chain 254 mm (10 in.) ; 9.53 mm (3/8 inch) pitch chain 305 mm (12 in.) ; 9.53 mm (3/8 inch) pitch chain
