Echo 9 Ultra H2 User Manual

30
How To Replace The Filter
H 2 WATER
When the LED filter life indicator light is on,
it is time to replace your filter.
1
2
Open the filter housing cover.
slide the cover to the left and remove it.
IMPORTANT! Stop water flow prior to filter replacement!
Take hold of the filter securely with your hand, press the top of filter firmly down
against the spring loaded mechanism (figure1) to disengage the top of the filter
then pull it toward you (figure 2) and up to remove it.
Once the upper part of the filter is separated
from housing by pressing firmly down.
and you have engaged the spring loaded
mechanism, You can easily remove the filter
from the main body by pulling it toward you.
Remove filter with the same as method above.
e
top
of
the
filter
3
Remove the expired filter.
A
A
B
B
A
Echo® 9 Ultra Replacement Filter
B
H2 Water Replacement Filter

Echo 9 Ultra H2 Specifications

General

Brand	Echo
Model	9 Ultra H2
Category	Water Filtration Systems
Language	English
