Echo 9 Ultra H2 - Cold Water Valve Installation; Cold Water Valve Installation Steps

2
Connect 1/4 in.(PE) hose to the
t-adapter in "Figure 2"
3
Push the 1/4in.(PE) hose all the
way in the water inlet at the bottom
of the machine.
4
Connect stainless steel acid line
to the acidic outlet and allow it to
drain into your sink.
5
After finishing the connection of
"Figure 4" open the water supply
valve and adjust the water
pressure.
6
Check for leaks on all connections
after installation completed.
18
Installation Procedure 2
Before installing, shut o water supply.
Caution
1
Loosen the nut of the cold water
valve.
[Figure 1]
[Figure 5]
Cold water valve
[Figure 2]
PE Hose
t-adapter
inlet
inlet
[Figure 4]
outlet
[Figure 3]
[Figure 6]
